VELOX VITA 6100 Analogue Addressable 4G Fire Detection and Alarm Control Panel

Product Number: VT-6100


VELOX VITA is marking a new era of innovation in fire detection and alarm system technology. Fully integrated with the VELOX range of devices and protocol, it surpasses the performance  of any traditional addressable panels in the market by far. Based on state of the art 32-bit microprocessor technology, the VELOX VITA can communicate swiftly over a 2Km loop length, fully loaded with 240 loop devices. The touch screen user interface enhances the user’s experience by making navigation through menus, programming and response times swifter, easier and more effective.

The Innovative VELOX VITA Introducing the unique ‘Bakhoor Mode’ feature which will help eliminate unwanted Alarms caused by burning incense, charcoal, smoking and even cooking in the home.  The Bakhoor mode is easily activated by the home owner and gives a unique timed ‘filter’ that will ignore smoke activations from specific detectors for the timed period. Once the timed period has expired the detectors will revert to their normal detection state. Whilst in Bakhoor mode the multi-sensor detectors will still detect heat thus ensuring a ‘real’ fire will still be detected and the alarm triggered in the normal way.


Read More Order Inquiry


Key Features



Smart Fire Detection & Alarm Control Panel Based on 4G & IoT Technology.

  • 4G Connectivity with Fully redundant Ethernet connection.
  • Fully IoT based design for smart city connectivity and applications.
  • Fully EN54 part 2 & 4 Certified.
  • One loop with 240 devices loop powered.


VELOX VITA Video





NO MORE.. nuisance Alarms
with SMART Fire Detection Technology

  • The Innovative VELOX VITA Introducing the unique ‘Bakhoor Mode’ feature which will help
    eliminate unwanted Alarms caused by burning incense, charcoal, smoking and even cooking
    in the home.
  • Advanced enable /disable and false alarm rejection technology ( Bakhoor Mode).
  • Aesthetically pleasing coloured LED panel lighting


Bakhoor Mode




Smart Monitoring & Controlling remotely over
VELOX CLOUD.

  • Fully Monitored GUI ‘‘Graphical User Interface’’.
  • Comprehensive maintenance over any smart device.
  • Direct reporting to Civil Defence & Maintenance service provider.
  • Pinpoints the fire incident location and fire spread


VELOX CLOUD Video







FULLY Approved by EN54 2&4 And UAE civil Defense
It’s Ready For Shipping

  • Fully colored Touch Screen panel.
  • Support 10 languages and more to come.
  • Fully loop powered topology
  • First fix and semi-flush enclosure with multiple color finish




All of the above features coming
inside30x30cm enclosure!!

  • Semi/Full-Flushed panel
  • Available in Different Colors ( Black, White, Grey)
  • Aesthetically pleasing colored LED panel lighting.





Techinical Specs

FUNCTIONAL FEATURES

Operating keyboard

Touchscreen

Optical messages

Led

Acoustic messages

Buzzer

Visualisation of the events

480×272 TFT 4.3”

Serial output for PC

N° 1 – RS232

Event log

Max. 850

Working mode

Guarded/Unguarded

Programming/Management hardware

Multilevel password

Number of analogue lines

One loop is Expandable To 9 loops

Exclusion of the analogue line

Single – multiple

I/O Modules / Detectors for each line

Max. 240

Programming type

Manual or by PC

Configuration of the analogue line

192 software zones

Analogue lines connection

Open or closed loop

Length of the detector lines

Max. 2000m

Type of cable

Shielded



Downloads

VELOXVITA 6100 -Datasheet (193.86 KB)
